DUU 1000-2 Recirculation conversion kit for for KMDA 7633 FL and CSDA 10x0
Recirculation conversion kit for CSDA 10x0 / CSDA 7xxx FL / KMDA for ducted recirculation mode including reactivatable charcoal filter
- Installation in plinth heights from 100 mm
- Exhaust air conn. to left, right and/or rear incl. 2 connectors
- Multiple DUU 1000-2 can be combined
- including Longlife AirClean filter can be regenerated
- Uniform airflow in recirculation mode
$ 808.00
In stock
Description
11207310
- Installation in plinth heights from 100 mm
- Exhaust air conn. to left, right and/or rear incl. 2 connectors
- Multiple DUU 1000-2 can be combined
- including Longlife AirClean filter can be regenerated
- Uniform airflow in recirculation mode
Installation Drawings
Find all installation drawings below
DUU1000-2, DUU1500 (installation drawing)
1) Stub for vent connection., A second stub for connecting another vent box is supplied., The stubs can be mounted on the right, left or at the rear., Extraction Connection for flat ducting system 222 x 89 mm, Cutout dimension in the plinth strip 350 mm x 98 mm
